Label Die Cutter – C5 Series

C5 is a digital die-cutting machine with multiple functions such as correction, re-laminating, slitting, waste removing, single-sheet cutting, collecting. It realize roll-to-roll cutting and roll-to-sheet cutting at the same time, easier operating than knife mold cutting. The cutting heads can adjust the space between them automatically. C5 also supporting intelligent buffer control system to realize automatic and high speed cutting..

Keywor:

cutting function speed

Classificar:

Label cutter

E-mail：

sales@ameida.com.cn

Message

Back to previous

Advantage：

1. Automatic rectification function: guarantee continuous cutting precision, unattended automatic cutting.

2. Touch screen: self-sustaining R&D operating system, easy to operate.

3. Multi-head cutting function: Max to 3 heads simultaneous cutting, high efficiency.

4. Platform suction cutting system: support kiss cut and full cut.

5. Waste removing function, Slitting function, collecting function, laminating function, re-laminating function, single-sheet cutting function.

6. Imported wire rail, Mitsubishi Motor, high precision.

Parameter：

Max Media Roller	Diameter 450mm
Cutting Media Width	40-300mm
Max Cutting Width	300mm
Min Label Length	10mm
Max Label Length	400mm
Max Cutting Speed	8m/min
Max Line Cutting Speed	1200mm/s
Cutting Heads	3pcs(space adjust automatically)
Slitting Blades	4pcs
Tools	Special alloy rotary blade
Cutting Precision	≤0.1mm
Cutting Tracking	Single mark or double mark
Slitting Speed	≤60m/min
Slitting Width	10-310mm
Slitting Precision	≤0.1mm
Machine Size	200012001400mm(LWH)
Machine Weight	1000KGS
Power	AC220 50~60Hz 4KW
